PANELOGIC™ CUSTOM COMPOSITE PANELS
CUSTOMIZE A PANEL TO DELIVER AN OPTIMUM BALANCE OF CHARACTERISTICS THAT SUIT YOUR NEEDS
Vixen Custom Composite Panels deliver a balance of properties for superior performance in a variety of applications. Available in a wide variety of cores, our sandwich panels incorporate both chemical and mechanical bonding, providing increased strength, performance and durability.
OPTIONS
Based on your specifications, Vixen Custom Composite Panels are custom made in thicknesses from 0.155” to 4”, and widths up to 120” (10 feet). A wide variety of standard cores are available, and Vixen Composites can apply the specific material combination for your precise application. UV-stability and corrosion resistance can be fine tuned to your specifications. Additionally, pigmentation and fire retardancy can be added to our proprietary formulations to meet your application requirements.
SYNTHETIC CORE PANELS
LOW DENSITY CORE OPTIONS:
- Polyiso
- PET
- Honeycomb
- Other specialty coring options
VARIETY OF REINFORCEMENTS TO MEET SPECIFIC PERFORMANCE REQUIREMENTS:
- Knit multi-axial E and ECR fiberglass reinforcements
- Woven bi-axial E and ECR fiberglass reinforcements
- High performance fiberglass reinforcements: H-glass and S-glass
- High performance reinforcement alternatives: Carbon Fiber, Aramid, Kevlar, etc
BENEFITS:
- Light weight
- Water resistance
- High strength-to-weight ratio
- Will not rot
- Consistent performance
- No glue lines
WOOD CORE PANELS
Engineered materials to meet specific weight and performance requirements as shown below:
WOOD-BASED CORE OPTIONS:
- Balsa
- APA Rated Plywood
BENEFITS:
- No glue lines
- Good fastener withdraw
- Improved water resistance of outer skins
